TFR0005 Freightliner FL50-60-70-80 Radiator (1997–2001)

Year Coverage

TFR0005 is a downflow radiator for the Freightliner FL50-60-70-80, model years 1997 to 2001.

The core measures 28.625" high by 24.75" wide, 2.25" deep. It has a 2" inlet at the left and a 2" outlet at the right. There is no integral oil cooler and no filler neck.

It replaces 69 OEM and aftermarket numbers, among them FRE12, 800012, 800012ST. Searching any one of them will find this part.

On radiators the inlet and outlet positions, and whether the unit carries an oil cooler, decide interchangeability more often than core size does. Two radiators with identical cores are frequently not interchangeable.
